WiFiBee WiFi Module - SMA with Antenna

WiFiBee WiFi Module - SMA with Antenna
WiFiBee WiFi Module - SMA with Antenna WiFiBee WiFi Module - SMA with Antenna WiFiBee WiFi Module - SMA with Antenna WiFiBee WiFi Module - SMA with Antenna WiFiBee WiFi Module - SMA with Antenna
Brand: Tinysine
Product Code: G5260F85B40D9A
Reward Points: 0
Availability: 275
Price: $36.00 $34.00

5 or more $32.50
20 or more $30.00
   - OR -

Description: The RN-XV module by Roving Networks is a certified Wi-Fi solution especially designed for customer who want to migrate their existing 802.15.4 architecture to a standard TCP/IP based platform without having to redesign their existing hardware. In other words, if your project is set up for XBee and you want to move it to a standard WiFi network, you can drop this in the same socket without any other new hardware.

The RN-XV module is based upon Roving Networks' robust RN-171 Wi-Fi module and incorporates 802.11 b/g radio, 32 bit processor, TCP/IP stack, real-time clock, crypto accelerator, power management unit and analog sensor interface.The module is pre-loaded with Roving firmware to simplify integration and minimize development time of your application. In the simplest configuration, the hardware only requires four connections (PWR, TX, RX and GND) to create a wireless data connection.

Note1:In order to configure this module, you will need an adapter lets you communicate with the module,before you can plug it and use on other modules.

Features:

  • Based on common 802.15.4 XBee footprint
  • Ultra low power: 4uA sleep mode, 38mA active
  • Onboard TCP/IP stack includes DHCP, UDP, DNS, ARP, ICMP, HTTP client, FTP client and TCP
  • Firmware configurable transmit power: 0dBm to 12dBm
  • Hardware interfaces:TTL UART
  • Host data rate up to 464Kbps over UART
  • Supports Adhoc and infrastructure networking
  • 8 general purpose digital I/O
  • 3 analog sensor inputs
  • Real-time clock for time-stamping, auto-sleep, and auto-wakeup modes
  • Accepts 3.3VDC regulated power supply
  • Wire antenna
